6.25.2 Texts only related to power management (AGC 14x)
Status text Condition Comment
Mains unit
UNIT STANDBY If redundant mains units are present, this message is
shown on the redundant unit.
TB TRIP EXTERNALLY Some external equipment has tripped the breaker. An external trip is log-
ged in the event log.
MOUNT CAN CONNEC-
TOR
Connect the power management CAN line
ADAPT IN PROGRESS The AGC is receiving the application that it has just
been connected to
SETUP IN PROGRESS The new AGC is being added to the existing applica-
tion
SETUP COMPLETED Successful update of the application in all AGC units
REMOVE CAN CONNEC-
TOR
Remove the power management CAN lines.
All units
BROADCASTING APPL. # Broadcast an application through the CAN line. Broadcasts one of the
four applications from
one unit to the rest of
the AGCs in the pow-
er management sys-
tem.
RECEIVING APPL. # AGC receiving an application.
BROADCAST COMPLE-
TED
Successful broadcast of an application.
RECEIVE COMPLETED Application received successfully.
BROADCAST ABORTED Broadcast terminated.
RECEIVE ERROR Application is not received correctly.
6.26 Counters
Counters for various values are included, and some of these can be adjusted if necessary, for instance if the
unit is installed on an existing genset or a new circuit breaker has been installed.
The table shows the adjustable values and their function in menu 6100:
AGC 100 Designer's Reference Handbook
4189340766 UK
Additional functions
DEIF A/S Page 90 of 152
