Dell EMC ML3 - Half-Height SAS Dual Port; Half-Height FC Single Port

Table 12. Half-height SAS dual port
Number Description
▌1▐ SAS port 0
▌2▐ SAS port 1
▌3▐ Drive sled indicators (see Figure 18 on page 13
Table 13. Half-height FC single port
Number Description
▌1▐ FC port 0
▌2▐ Drive sled indicators (see Figure 18 on page 13
Figure 19. Half-height SAS dual port
Figure 20. Half-height FC single port
14 Dell EMC ML3 Tape Library: User's Guide
