Dell EMC ML3 - Physical and Logical Addresses of Drives; Full-Height FC Dual Port

Table 14. Full-height FC dual port
Number Description
▌1▐ FC port 0
▌2▐ FC port 1
▌3▐ Drive sled indicators (see Figure 18 on page 13
Physical and logical addresses of drives
The library assigns each tape drive a unique address to indicate its physical location, shown in Figure 22
on page 16. The physical numbering is bottom up on all drives. This information is shown on the Drives
page of the Management GUI.
Figure 21. Full-height FC dual port
Overview 15
