Dell EMC ML3 - Management GUI Main Screen; Main Screen Elements

Table 26. Main screen elements
Element
▌1▐ Home icon > Current Navigation
▌2▐ Actions > dependent on current navigation
▌3▐ User logged in
▌4▐ Help
▌5▐ Navigation Dock
▌6▐ Overview - dependent on current navigation
▌7▐ Physical Capacity
▌8▐ Status Bar
▌9▐ Drive Activity
▌10▐ Library Status
Tips:
1. For specific management function navigation, see “Locating Management functions” on page 63.
2. Check the online help in the Management GUI for additional information. The help pages are
updated with firmware updates and often contain up-to-date technical details that might not be
contained in this document. To access Management GUI help, click the ? icon on the right side of the
Management GUI top banner.
Figure 55. Management GUI main screen
60 Dell EMC ML3 Tape Library: User's Guide
