Dell Networking N4000 Series User Manual

116 Hardware Overview
Figure 3-15. N4024 Front Panel
Figure 3-16. N4024F Front Panel
N4032 and N4032F switches can be stacked with other N4000 switches using
10G or 40G SFP+ or QSFP modules in the module bay.
The N4064 front panel provides 64 x 10GbE copper ports and two fixed
QSFP ports, each supporting 4 x 10G or 1 x 40G connections. The N4064F
front panel provides 64 SFP+ ports supporting SFP+ and SFP transceivers
plus two fixed QSFP ports, each supporting 4 x 10G or 1 x 40G connections.
10GbE Copper Ports Module bay
USB port
10GbE Fiber Ports Module bay
USB port

Dell Networking N4000 Series Specifications

General

Layer	Layer 3
Switching Capacity	Up to 1.28 Tbps
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Series	N4000 Series
Stacking	Up to 12 units
Power Supply	Dual, hot-swappable
Management	Web, CLI, SNMP
Humidity	10% to 90% (non-condensing)
