Dell Networking N4000 Series User Manual

Hardware Overview 123
Out-of-Band Ethernet Management Port LEDs
Table 3-20 shows the LED definitions for the OOB Ethernet management
port.
System LEDs
The system LEDs, located on the back panel, provide information about the
power supplies, thermal conditions, and diagnostics.
Table 3-19. QSFP Module LED Definitions
LED Color Definition
Link LED Off There is no link.
Solid green The port is operating at 40 Gbps.
Solid amber The port is operating at other speeds.
Activity LED Off There is no current transmit/receive activity.
Blinking green The port is actively transmitting/receiving.
Table 3-20. OOB Ethernet Management Port LED Definitions
LED Color Definition
Link LED Off There is no link.
Solid green The port is operating at 1000 Mbps.
Solid amber The port is operating at 10/100 Mbps.
Activity LED Off There is no current transmit/receive activity.
Blinking green The port is actively transmitting/receiving.

Dell Networking N4000 Series Specifications

General

Layer	Layer 3
Switching Capacity	Up to 1.28 Tbps
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Series	N4000 Series
Stacking	Up to 12 units
Power Supply	Dual, hot-swappable
Management	Web, CLI, SNMP
Humidity	10% to 90% (non-condensing)
