Dell Networking N4000 Series User Manual

818 Configuring L2 Multicast Features
Tab le 2 5-2 contains definitions for port/LAG IGMP management settings.
Adding and Configuring Bridge Multicast Address Groups
To configure a bridge multicast group:
1
From the Bridge Multicast Group page, click Add .
The
Add Bridge Multicast Group page displays.
Figure 25-3. Add Bridge Multicast Group
2 Select the ID of the VLAN to add to the multicast group or to modify
membership for an existing group.
3 For a new group, specify the multicast group IP or MAC address associated
with the selected VLAN.
Table 25-2. Port/LAG IGMP Management Settings
Port Control Definition
D Dynamic: Indicates that the port/LAG was dynamically joined to
the Multicast group (displays in the Current row).
S Static: Attaches the port to the Multicast group as a static member
in the Static row. Displays in the Current row once Apply is clicked.
F Forbidden: Indicates that the port/LAG is forbidden entry into the
Multicast group in the Static row. Displays in the Current row once
Apply is clicked.
Blank Blank: Indicates that the port is not attached to a Multicast group.
