Chapter 5 Parameters|VFD-M-D Series
Revision Jan. 2007, MDE2, SW V1.05 5-59
 The Multi-Function Input Terminals (refer to Pr.5-00 to 5-10) are used to select one of the AC
motor drive Multi-step speeds. The speeds (frequencies) are determined by Pr.5-17 to 5-32 as
shown above.
 When using with door control system (Pr.0-09=02/03/04), it will run the door open/close curve
by the output of position sensor to change speed.
 It is used to set multi-function input terminals FWD, REV and output status of Pr.5-00 to Pr.5-
10 to be normal open (N.O.) or normal closed (N.C.).
 Setting methods:
It needs to conver 13-bit binary value to decimal value before entering this parameter.
For example: Suppose that the initial status of REV, MI2, MI4, MI5, COM1, COM2 and COM4
is N.C. The initial status of FWD, MI1, MI3, A, B and COM3 is N.O. At this moment, you need
to input 5738 into Pr. 5-33 as shown in the following.
Weights
Bit
0=N.O
1=N.C
FWD =N.O
REV =N.C
MI1 =N.O
MI2 =N.C
MI3 =N.O
MI4 =N.C
MI5 =N.C
A =N.O
B =N.O
COM1 =N.C
COM2 =N.C
COM3 =N.O
COM4 =N.C
101011001101 0
The setting value
= bit14x2 +
12
bit13x2 +....+bit2x2 +bit1x2 +bit0x2
11 210
= 1x2 +
12
1x2 +1x2 +1x2 +1x2 +1x2 +1x2
1096531
=4096+1024+512+64+32+8+2
Setting 5-33
=5738
NOTE:
2 =16384 2 =8192 2 =4096 2 =2048 2 =1024
2 =512 2 =256 2 =128 2 =64 2 =32
2 =16 2 =8 2 =4 2 =2 2 =1
14 13 12 11 10
98765
43210
5 - 33
Multi-function Input Terminal Status (N.O/N.C)
Unit: 1
Settings
0 to 8191
Factory Setting: 0
