Delta VFD-M-D series User Manual

Chapter 5 Parameters|VFD-M-D Series
5-46 Revision Jan. 2007, MDE2, SW V1.05
Group 4: Door Close Parameters
4 - 00  Door Close High Speed 1 Unit: 0.01
Settings 0.00~400.0Hz Factory Setting: 30.00
4 - 01 Door Close Final Speed Start Unit: 0.1
Settings 0.0~100.0% (0.0%: close complete, 100.0%:
open complete)
Factory Setting: 4.0
4 - 02 Door Close Final Speed Unit: 0.01
Settings 0.00~400.0Hz Factory Setting: 5.00
4 - 03 Door Close Holding Speed Start Unit: 0.1
Settings 0.0~100.0% (0.0%: close complete, 100.0%:
open complete)
Factory Setting: 1.0
4 - 04 Door Close Holding Speed Unit: 0.01
Settings 0.00~400.0Hz Factory Setting: 2.00
4 - 05  Door Close Acceleration Time 1 Unit: 0.1
Settings 0.1~3600sec Factory Setting: 2.0
4 - 06  Door Close Deceleration Time 1 Unit: 0.1
Settings 0.1~3600sec Factory Setting: 2.0
4 - 07  Door Close High Speed 2 Unit: 0.01
Settings 0.00~400.0Hz Factory Setting: 20.00
4 - 08  Door Close Acceleration Time 2 Unit: 0.1
Settings 0.1~3600sec Factory Setting: 10.0
4 - 09  Door Close Deceleration Time 2 Unit: 0.1
Settings 0.1~3600sec Factory Setting: 10.0
 Pr.4-00 to Pr.4-09 can be used only when Pr.00-09 is set to 00 Distance control mode 1 or 01
Distance control mode 2.
 Please adjust by following diagram to meet your application.
