Delta VFD-M-D series User Manual

Chapter 5 Parameters|VFD-M-D Series
5-6 Revision Jan. 2007, MDE2, SW V1.05
Parameter Explanation Settings
Factory
Setting
Custome
r
2-29
ASR (Auto Speed
Regulation for Door
Close) control (with
PG only) (I)
0.00 to 100.00 (0.00 disable) 1.00
Group 3 Door Open Parameters
Parameter Explanation Settings
Factory
Setting
Customer
3-00 Door Open Coupling
Speed
0.00 to 400.0Hz 8.40
3-01 Door Open High
Speed Start
00 to 65535 (Pluses number) 300
3-02 Door Open High
Speed 1
0.00 to 400.0Hz 42.00
3-03 Door Open Final
Speed Start
0.0 to 100.0% 95.0
3-04 Door Open Final
Speed
0.00 to 400.0Hz 5.00
3-05 Door Open Holding
Speed Start
0.0 to 100.0% 99.0
3-06 Door Open Holding
Speed
0.00 to 400.0Hz 2.00
3-07 Door Open
Acceleration Time 1
0.1 to 3600sec 2.0
3-08 Door Open
Deceleration Time 1
0.1 to 3600sec 2.0
3-09 Door Open High
Speed 2
0.00 to 400.0Hz 30.00
3-10 Door Open
Acceleration Time 2
0.1 to 3600sec 10.0
3-11 Door Open
Deceleration Time 2
0.1 to 3600sec 10.0
3-12 Door Open Holding
Torque
0.0 to 100.0% 30.0
3-13 Response Time of
Door Open Holding
Torque
0.01 to 10.00sec 0.20
3-14 Door Open Time-out
Setting
0.0 to 180.0sec (0.0: disable) 0.0
3-15 The Current Level 1
to Decrease to Pr.3-
12 after Door Open
Completed
0.0 to 150.0% 0.0%
3-16 The Current Level 2
to Decrease to Pr.3-
12 after Door Open
Completed
0.0 to 150.0% 0.0%
3-17 Holding Time for
Terminal REV
0.0 to 999.9 sec (999.9 sec for always
holding)
0.0
