Chapter 5 Parameters|VFD-M-D Series
Revision Jan. 2007, MDE2, SW V1.05 5-7
Parameter Explanation Settings
Factory
Setting
Customer
3-18 S Curve Acceleration
Time for Door Open
0.0 to 10.0 sec
0.0
Group 4 Door Close Parameters
Parameter Explanation Settings
Factory
Setting
Customer
4-00 Door Close High
Speed 1
0.00 to 400.0Hz 30.00
4-01 Door Close Final
Speed Start
0.0 to 100.0% 4.0
4-02 Door Close Final
Speed
0.00 to 400.0Hz 5.00
4-03 Door Close Holding
Speed Start
0.0 to 100.0% 1.0
4-04 Door Close Holding
Speed
0.00 to 400.0Hz 2.00
4-05 Door Close
Acceleration Time 1
0.1 to 3600sec 2.0
4-06 Door Close
Deceleration Time 1
0.1 to 3600sec 2.0
4-07 Door Close High
Speed 2
0.00 to 400.0Hz 20.00
4-08 Door Close
Acceleration Time 2
0.1 to 3600sec 10.0
4-09 Door Close
Deceleration Time 2
0.1 to 3600sec 10.0
4-10 Re-open Current
Level 1
0.0 to 150.0% 100.0
4-11 Re-open Current
Level 1 for
Acceleration Area
100~200% (100% is Pr.4-10 setting) 150
4-12 Re-open Current
Level 2
0.0 to 150.0% 100.0
4-13 Re-open Current
Level 2 for
Acceleration Area
100~200% (100% is Pr.4-12 setting) 150
4-14 Re-open
Deceleration Time
0.1 to 3600sec 0.2
4-15 Door Close Holding
Torque
0.0 to 100.0% 50.0
4-16 Response Time of
Door Close Holding
Torque
0.01 to 10.00sec 0.20
4-17 Re-open Low Speed
Area
1.0 to 99.0% (100% is the door width, low
speed area is 0%~Pr. 4-17)
2.0
4-18 Re-open
Acceleration
Boundary
8.0 to 97.0% (100% is the door width,
acceleration area is Pr. 4-18~100%)
70.0
4-19 Door Close Time-out
Setting
0.0 to 180.0sec (0.0: disable) 0.0
