Delta VFD-M-D series User Manual

Chapter 5 Parameters|VFD-M-D Series
5-2 Revision Jan. 2007, MDE2, SW V1.05
5.1 Summary of Parameter Settings
: The parameter can be set during operation.
Group 0 User Parameters
Parameter Explanation Settings
Factory
Setting
Customer
0-00 Identity Code of the
AC motor drive
Read-only ##
0-01 Rated Current
Display of the AC
motor drive
Read-only #.#
08: Keypad lock
09: All parameters are reset to factory settings
(50Hz, 220V)
0-02 Parameter Reset
10: All parameters are reset to factory settings
(60Hz, 220V)
00
00: Display the frequency command value (F)
01: Display the actual output frequency (H)
02: Display the content of user-defined unit (U)
03: Multifunction display, see Pr.0-04
0-03
Start-up Display
Selection
04: FWD/REV command
00
00: Display output current (A)
01: Display the pulses
02: Display the walking distance and step
speed (1.tt)
03: Display DC-BUS voltage (
u
)
04: Display output voltage (E)
05: Output power factor angle (n)
06: Display output power (P)
07: Display actual motor speed
08: Display the estimated value of torque as it
relates to current (t)
09: Display PG numbers/10ms (G)
10: Display the temperature of heat sink (°C)
11: Display external input terminal status (I.)
0-04
Content of Multi
Function Display
12: Display external output terminal status (o.)
13: Display communication address (d.)
00
0-05
User-Defined
Coefficient K
0.01 to 160.0 1.00
0-06 Software Version Read-only #.##
0-07 Password Input 00 to 9999 00
0-08 Password Set 00 to 9999 00
00: Distance control mode 1
01: Distance control mode 2
02: Multi-step control mode 1
03: Multi-step control mode 2
0-09 Door Control Mode
04: Multi-step control mode 3
05: Multi-step control mode 4
00
