Chapter 5 Parameters|VFD-M-D Series
5-20 Revision Jan. 2007, MDE2, SW V1.05
3 chances to enter the correct
password.
1st time displays "01" if
password is incorrect.
2nd time displays "02", if
password is incorrect.
3rd time displays "Pcde"
(blinking)
If the password was entered
incorrectly after three tries,
the keypad will be locked.
Turn the power OFF/ON to
re-enter the password.
Incorrect Password
END
Displays 00 when
entering correct
password into
Pr.0-07.
0-08 0-07
0-07
Displays 00 when
entering correct
password into
Pr.0-07.
Correct Password
END
0-08
0 - 09
Door Control Mode
Factory Setting: 00
Settings 00 Distance control mode 1
01 Distance control mode 2
02 Multi-step control mode 1
03 Multi-step control mode 2
04 Multi-step control mode 3
05 Multi-step control mode 4
 This parameter is used to select the control mode of AC motor drives. Refer to the following
explanation for detail.
 00 Distance control mode 1
The drive is controlled by sensorless control. It should be set the Pr.2-11~Pr.2-14 correctly. It
will store the door width in Pr.2-24 and Pr.2-25 by Auto-tuning. It operates the door for speed
switch and completed position by counting the PG pulses. In this mode, position function will
be executed whenever power again and operates with low speed to the 0% or 100% door
width by the operation direction.
