Delta VFD-M-D series User Manual

Chapter 5 Parameters|VFD-M-D Series
5-10 Revision Jan. 2007, MDE2, SW V1.05
Parameter Explanation Settings
Factory
Setting
Customer
5-34 Reset after re-
open/re-close
Bit0=0: Disable to detect the incorrect
open/close limit
Bit0=1: Enable to detect the incorrect
open/close limit
Bit1=0: Enable to re-open when door close
error
Bit1=0: Disable to re-open when door close
error
Bit2=0 Enable S-Curve when re-open
Bit2=1 Disable S-Curve when re-open
00
Group 6 Digital Output Parameters
Parameter Explanation Settings
Factory
Setting
Customer
00: No function
01: AC drive operational
02: Master frequency attained
6-00
Multi-function Output
(RA1, RB1, RC1)
03: Over-Torque Detection
00
04: Low-Voltage Indication
05: Operation Mode Indication
06: Fault Indication
6-01
Multi-function Output
(RA2, RC2)
07: Warning Indication
00
08: Demo Indication
09: A Step Completed
10: A Demo Completed
6-02
Multi-function Output
MO1
(communication)
11: Forced Stop Indication
00
12: Heat Sink Overheat Warning
13: AC Drive Ready
14: Emergency Stop
6-03
Multi-function Output
MO2
(communication)
15: Soft Braking Signal
00
16: Zero Speed Output Signal
17: Feedback Signal Error
18: Position Detection 1
6-04
Multi-function Output
MO3
(communication)
19: Position Detection 2
00
20: Position Detection 3
6-05
Multi-function Output
MO4
(communication)
21: The signal outputs when it is in close
completed position
00
