Delta VFD-M-D series User Manual

Chapter 5 Parameters|VFD-M-D Series
Revision Jan. 2007, MDE2, SW V1.05 5-9
Parameter Explanation Settings
Factory
Setting
Customer
23: The signal when it is in open completed
position, including RUN signal
24: The signal when it is in close completed
position, including RUN signal
00: Disable 5-11 Line Start Lockout
01: Enable
00
00: 2-wire (FWD/STOP, REV/STOP) 5-12 2-wire Operation
Control Mode
01: 2-wire (FWD/REV, RUN/STOP)
00
5-13 Digital Terminal Input
Debouncing Time
01 to 20 (*2.5ms) 01
5-14 Waiting Time for
Next Demo
0.1 to 999.9sec 2.0
5-15 The Record for
Demo Times
00 to 9999 00
00: Disable 5-16 Clear Demo Times
01: Enable
00
5-17 1
st
Step Speed
Frequency
0.00 to 400.0 Hz 0.00
5-18 2
nd
Step Speed
Frequency
0.00 to 400.0 Hz 0.00
5-19 3
rd
Step Speed
Frequency
0.00 to 400.0 Hz 0.00
5-20 4
th
Step Speed
Frequency
0.00 to 400.0 Hz 0.00
5-21 5
th
Step Speed
Frequency
0.00 to 400.0 Hz 0.00
5-22 6
th
Step Speed
Frequency
0.00 to 400.0 Hz 0.00
5-23 7
th
Step Speed
Frequency
0.00 to 400.0 Hz 0.00
5-24 8
th
Step Speed
Frequency
0.00 to 400.0 Hz 0.00
5-25 9
th
Step Speed
Frequency
0.00 to 400.0 Hz 0.00
5-26 10
th
Step Speed
Frequency
0.00 to 400.0 Hz 0.00
5-27 11
th
Step Speed
Frequency
0.00 to 400.0 Hz 0.00
5-28 12
th
Step Speed
Frequency
0.00 to 400.0 Hz 0.00
5-29 13
th
Step Speed
Frequency
0.00 to 400.0 Hz 0.00
5-30 14
th
Step Speed
Frequency
0.00 to 400.0 Hz 0.00
5-31 15
th
Step Speed
Frequency
0.00 to 400.0 Hz 0.00
5-32 16
th
Step Speed
Frequency
0.00 to 400.0 Hz 0.00
5-33 Multi-function Input
Terminal Status
(N.O/N.C)
0~8191 0
