Chapter 5 Parameters|VFD-M-D Series
Revision Jan. 2007, MDE2, SW V1.05 5-27
When this parameter is NOT set to 00 “No limit signal” and Pr. 0-17 is NOT set to 0, it will be
regarded as open/close complete position with following two conditions.
A. It has open/close limit signal.
B. When the current exceeds this level due to motor stall.
When this parameter is set to 00 “No limit signal”, the methods for detecting open/close
complete position are as follows.
A. When Pr. 0-17 is set to 0: When PG feedback frequency is almost 0 due to motor stall, it is
regarded as open/close complete position.
B. When Pr. 0-17 is NOT set to 0: When current exceeds this level due to motor stall, it is
regarded as open/close complete position.
NOTE
It is recommended to use method B for the transmission mechanism skids easily.
This function is only for the distance control mode. For multi-step control mode, please use the multi-
input terminals (set one of Pr.5-00~Pr.5-10 to 17, 18, 23 or 24).
0 - 17
Stall Current Level of Position Mode
Unit: 0.1
Settings 0.0 to 200.0% Factory Setting: 30.0
This parameter is used for the stall current level for open/close complete position and used
with Pr.0-15.
0 - 16 Fan Control
Factory Setting: 03
Settings 00 Fan always ON
01 1 minute after AC motor drive stops, fan will be OFF
02 AC motor drive runs and fan ON, AC motor drive stops and fan
OFF
03 Fan ON to run when preliminary heatsink temperature attained
This parameter determines the operation mode of cooling fan.
0 - 18
Control Method
Factory Setting: 00
Settings 00 V/F control
01 Vector Control
