Delta VFD-M-D series User Manual

Chapter 5 Parameters|VFD-M-D Series
Revision Jan. 2007, MDE2, SW V1.05 5-11
Parameter Explanation Settings
Factory
Setting
Customer
22: The signal outputs when it is in open
completed position
6-06
Multi-function Output
MO5
(communication)
23: Door Close Error
00
24: Reserved
25: Position Complete Signal
6-07
Multi-function Output
MO6
(communication)
26: Reserved
00
6-08
Multi-function Output
status
00 to 255
00
6-09 Position Detection 1 0.0 to 100.0%
25.0
6-10 Position Detection 2 0.0 to 100.0%
12.5
6-11 Position Detection 3 0.0 to 100.0%
7.5
6-12
|
6-15
Reserved
6-13 Reserved
6-14 Reserved
6-15 Reserved
Group 7 Protection and Special Parameters
Parameter Explanation Settings
Factory
Setting
Custome
r
7-00
Software Braking
Level
370~430 Vdc
380
7-01
DC Braking Current
Level
0.0 to 100.0 %
0.0
7-02
DC Braking Time
during Start-Up
0.0 to 999.9 sec
0.0
7-03
DC Braking Time
during Stopping
0.0 to 999.9 sec
0.0
7-04
Start-Point for DC
Braking
0.00 to 400.0Hz
0.00
00: Disabled
01: Enabled during constant speed operation
and continues until oL/oL1 is reached.
02: Enabled during constant speed operation
and halted after oL2 detection
03: Enabled during Accel/constant speed
operation and continues until oL/oL1 is
reached
7-05
Over-Torque
Detection Mode
04: Enabled during Accel/constant speed
operation and halted after oL2 detection
00
7-06
Over-Torque
Detection Level
10.0 to 200.0%
150.0
