Chapter 5 Parameters|VFD-M-D Series
5-38 Revision Jan. 2007, MDE2, SW V1.05
The fault code will be displayed when the auto-tuning time is more than 180 seconds
and it means fail to auto-tuning.
2 - 24 Door Width Pulses (Unit: 1) Unit: 1
Settings 00~9999 Factory Setting: 7500
2 - 25 Door Width Pulses (Unit: 10000) Unit: 1
Settings 00~99 Factory Setting: 00
After setting Pr. 2-23 to 01 and finishing execution, door width pulses will auto fill into Pr.2-24
and Pr.2-25.
2 - 26 Reserved
2 - 27 Reserved
2 - 28
ASR (Auto Speed Regulation for door close) control (with
PG only) (P)
Unit: 0.1
Settings 0.0 to 10.0 Factory Setting: 0.5
This parameter specifies Proportional control and associated gain (P), and is used for speed
control with PG (encoder) feedback.
NOTE
The parameter can be set during operation for easy tuning.
2 - 29
ASR (Auto Speed Regulation for door close) control (with
PG only) (I)
Unit: 0.01
Settings 0.00 to 100.00 Factory Setting: 1.00
0.00 disable
This parameter specifies Integral control and associated gain (I), and is used for speed control
with PG (encoder) feedback.
NOTE
The parameter can be set during operation for easy tuning.
