Delta VFD-M-D series User Manual

Chapter 5 Parameters|VFD-M-D Series
Revision Jan. 2007, MDE2, SW V1.05 5-39
Group 3: Door Open Parameters
3 - 00 Door Open Coupling speed Unit: 0.01
Settings 0.00~400.0Hz Factory Setting: 8.40
3 - 01 Door Open High Speed Start Unit: 1
Settings 00~65535 (pulse number) Factory Setting: 300
3 - 02  Door Open High Speed 1 Unit: 0.01
Settings 0.00~400.0Hz Factory Setting: 42.00
3 - 03 Door Open Final Speed Start Unit: 0.01
Settings 0.0~100.0% (0.0%: close complete, 100.0%:
open complete)
Factory Setting: 95.0
3 - 04 Door Open Final Speed Unit: 0.01
Settings 0.00~400.0Hz Factory Setting: 5.00
3 - 05 Door Open Holding Speed Start Unit: 0.1
Settings 0.0~100.0% (0.0%: close complete, 100.0%:
open complete)
Factory Setting: 99.0
3 - 06 Door Open Holding Speed Unit: 0.01
Settings 0.00~400.0Hz Factory Setting: 2.00
3 - 07  Door Open Acceleration Time 1 Unit: 0.1
Settings 0.1~3600sec Factory Setting: 2.0
3 - 08  Door Open Deceleration Time 1 Unit: 0.1
Settings 0.1~3600sec Factory Setting: 2.0
3 - 09  Door Open High Speed 2 Unit: 0.01
Settings 0.00~400.0Hz Factory Setting: 30.00
3 - 10  Door Open Acceleration Time 2 Unit: 0.1
Settings 0.1~3600sec Factory Setting: 10.0
3 - 11  Door Open Deceleration Time 2 Unit: 0.1
Settings 0.1~3600sec Factory Setting: 10.0
 The unit of Pr.3-01 is pulse number. It should be less than Pr.3-03 after converting to %.
 Please adjust by following diagram to meet your application.
