Delta VFD-M-D series User Manual

Chapter 5 Parameters|VFD-M-D Series
Revision Jan. 2007, MDE2, SW V1.05 5-13
Parameter Explanation Settings
Factory
Setting
Custome
r
20: Software/password protection
(PcdE/Ccde)
21: Reserved
22: Reserved
23: Reserved
24: Reserved
25: Reserved
26: PG feedback error (PGEr)
27: Door open/close complete signal error
(PSEr)
28: Door open time-out (doEr)
7-18
Fourth Most Recent
Fault Record
35: Communication time-out (CE10)
00
7-19
Accumulative Motor
Operation Time
(Min.)
00 to 1439 min
00
7-20
Accumulative Motor
Operation Day
00 to 9999 day
00
Group 8 Communication Parameters
Parameter Explanation Settings
Factory
Setting
Custome
r
8-00
Communication
Address
01 to 254
01
00: Baud rate 4800bps
01: Baud rate 9600bps
02: Baud rate 19200bps
8-01 Transmission Speed
03: Baud rate 38400bps
02
00: Warn and keep operating
01: Warn and ramp to stop
02: Warn and coast to stop
8-02
Transmission Fault
Treatment
03: No warning and keep operating
03
8-03 Time-out Detection 0.0 ~ 60.0 seconds (0.0: Disable) 0.0
00: 7,N,2 (Modbus, ASCII)
01: 7,E,1 (Modbus, ASCII)
02: 7,O,1 (Modbus, ASCII)
03: 8,N,2 (Modbus, RTU)
8-04
Communication
Protocol
04: 8,E,1 (Modbus, RTU)
03
