Appendix B Accessories
|
VFD-M-D S
eries
B-2
Rev
ision Jan. 20
07, MDE2, S
W
V1.05
B.1.1 Dimension
s and Weights for Braking
Resistors
(Dimensions are in
millimeter)
TYPE L1
L2
H
D
W
MAX.
WEIGHT(g)
BR080W200 140
125
20
5.3
60
160
144
146
