Chapter 5 Parameters|VFD-M-D Series
Revision Jan. 2007, MDE2, SW V1.05 5-15
5.2 Description of Parameter Settings
Group 0: User Parameters : The parameter can be set during operation.
0 - 00 Identity Code of the AC Motor Drive
Settings Read Only Factory setting: ##
0 - 01 Rated Current Display of the AC Motor Drive
Settings Read Only Factory setting: #.#
Pr. 0-00 displays the identity code of the AC motor drive. The capacity, rated current, rated
voltage and the max. carrier frequency relate to the identity code. Users can use the following
table to check how the rated current, rated voltage and max. carrier frequency of the AC motor
drive correspond to the identity code.
Pr.0-01 displays the rated current of the AC motor drive. By reading this parameter the user
can check if the AC motor drive is correct.
kW HP Pr.0-00
Rated Output
Current (A)
Max. Carrier
Frequency
230V Series
0.4 0.5 00 2.5 15KHz
0 - 02
Parameter Reset
Factory Setting: 00
Settings 08 Keypad Lock
09 All parameters are reset to factory settings (50Hz, 220V)
10 All parameters are reset to factory settings (60Hz, 220V)
This parameter allows the user to reset all parameters to the factory settings except the fault
records (Pr.7-15 ~ Pr.7-18).
50Hz: Pr.1-01 is set to 50Hz and Pr.1-02 is set to 230V.
60Hz: Pr.1-01 is set to 60Hz and Pr.1-02 is set to 230V.
When Pr.0-02=08, the keypad is locked. To unlock the keypad, set Pr.0-02=00.
