Chapter 2 Installation and Wiring|VFD-M-D Series
2-4 Revision Jan. 2007, MDE2, SW V1.05
LC-M2E
2.4 Wiring
After removing the front cover, check if the power and control terminals are clear of debris. Be sure to
observe the following precautions when wiring.
General Wiring Information
Applicable Codes
All VFD-M-D series are Underwriters Laboratories, Inc. (UL) and Canadian Underwriters
Laboratories (cUL) listed, and therefore comply with the requirements of the National Electrical
Code (NEC) and the Canadian Electrical Code (CEC).
Installation intended to meet the UL and cUL requirements must follow the instructions provided
in “Wiring Notes” as a minimum standard. Follow all local codes that exceed UL and cUL
requirements. Refer to the technical data label affixed to the AC motor drive and the motor
nameplate for electrical data.
