Delta VFD-M-D series User Manual

Chapter 5 Parameters|VFD-M-D Series
5-8 Revision Jan. 2007, MDE2, SW V1.05
Parameter Explanation Settings
Factory
Setting
Customer
4-20 The Current Level 1
to Decrease to Pr.4-
15 after Door Close
0.0~150.0%
0.0%
4-21 The Current Level 2
to Decrease to Pr.4-
15 after Door Close
0.0~150.0%
0.0%
4-22 Holding Time for
Terminal FWD
0.0 to 999.9 sec (999.9 sec for always
holding)
0.0
4-23 S Curve Acceleration
Time for Door Close
0.0 to 10.0 sec
0.0
4-24 Re-open Current
Level 1 for Low
Speed
0.0~150.0%
100.0
4-25 Re-open Current
Level 2 for Low
Speed
0.0~150.0%
100.0
Group 5 Multi-Step Speed and PLC Parameters
Parameter Explanation Settings
Factory
Setting
Customer
00: No function 5-00 Multi-Function Input
Terminal (MI1)
01: Multi-step speed command 1
00
02: Multi-step speed command 2
5-01
Multi-Function Input
Terminal (MI2)
03: Multi-step speed command 3
00
04: Multi-step speed command 4 5-02 Multi-Function Input
Terminal (MI3)
05: 1st/2nd Accel/decel Time Selection
00
5-03 Multi-Function Input
Terminal (MI4)
06: Low speed operation 00
07: FWD/REV command for low speed
operation
00
08: Demo mode
5-04
Multi-Function Input
Terminal (MI5)
09: Force stop (NO)
10: Force stop (NC) 5-05 Multi-Function Input
Terminal (A)
11: Emergency stop (NO)
00
12: Emergency stop (NC) 5-06 Multi-Function Input
Terminal (B)
13: Operation command selection
(Keypad/external terminal)
00
14: Parameter lock enable (NC) 5-07 Multi-Function Input
Terminal (COM1)
15: Reset (NO)
00
16: Reset (NC) 5-08 Multi-Function Input
Terminal (COM2)
17: The signal when it is in open completed
position
00
18: The signal when it is in close completed
position
5-09 Multi-Function Input
Terminal (COM3)
19: Open allowance signal
00
20: Force door open signal
21: Home return
5-10 Multi-Function Input
Terminal (COM4)
22: The curve selection for 1st/2nd step door
open/close
00
