Revision Jan. 2007, MDE2, SW V1.05
Appendix A Specifications
Voltage Class 230V Class
Model Number VFD-XXXM-D 004
Max. Applicable Motor Output
(kW)
0.4
Max. Applicable Motor Output (hp)
0.5
Rated Output Capacity
(kVA)
1.0
Rated Output Current (A) 2.5
Maximum Output Voltage
(V)
3-Phase Proportional to Input Voltage
Output Frequency (Hz) 0.1~400 Hz
Output Rating
Carrier Frequency (kHz) 1-15
Single
Rated Input Current (A)
6.3
Rated Voltage/Frequency
Single/3-phase
200-240 V, 50/60Hz
Voltage Tolerance
±
10%(180~264 V)
Input Rating
Frequency Tolerance
±
5%(47~63 Hz)
Cooling Method Fan Cooled
Weight (kg) 2.2
Control System
SPWM(Sinusoidal Pulse Width Modulation) control (V/f or sensorless vector
control)
Frequency Setting
Resolution
0.01Hz
Output Frequency
Resolution
0.01Hz
Torque Characteristics
Including the auto-torque, auto-slip compensation; starting torque can be 150%
at 1.0Hz
Overload Endurance 150% of rated current for 1 minute
Skip Frequency Three zones, settings range 0.1-400Hz
Accel/Decel Time 0.1 to 3600 seconds (2 Step settings for Accel/Decel time)
DC Braking
Operation frequency 0.1-400.0Hz, output 0-100% rated current
Start time 0.0-99.9 seconds, stop time 0.0-99.9 seconds
Regenerated Braking
Torque
Approx. 20%(up to 125% possible with option braking resistor externally
mounted)
Control Characteristics
V/f Pattern Adjustable V/f pattern
