Delta VFD-M-D series User Manual

Appendix A Specifications|VFD-M-D Series
A-2 Revision Jan. 2007, MDE2, SW V1.05
Voltage Class 230V Class
Keypad
Setting by
Frequency
Setting
External Signal RS-485 interface; Multi-Function Inputs 1 to 5 (15 steps and Jog)
Keypad Set by RUN and STOP Operation
Setting
Signal
External Signal
2 wires (Fwd, Rev, RUN), JOG operation, RS-485 serial interface, demo mode
Multi-Function Input Signal
Multi-step selection 0 to 5, Jog, first to second accel/decel switches, driver reset,
force stop, emergency stop, operation command source, parameter lock, demo
mode, open/close limit signal, open allowance signal, force open signal, re-
position, 1
st
/2
nd
step open/close curve selection
Operating Characteristics
Multi-Function Output
Indication
AC drive operating, frequency attained, fault indication, driver is ready, overheat
alarm, emergency stop, over torque, over voltage, operation mode, alarm
indication, demo mode indication, zero speed indication, position detection, limit
signal, re-open/close indication, position finished
Alarm Output Contact
Contact will be On when it malfunctions (1 Form C contact or 1 Form A contact
or 2 open collector outputs)
Operation Functions
AVR, fault records, reverse inhibition, DC braking, auto torque/slip
compensation, auto tuning, adjustable carrier frequency, output frequency limits,
parameter lock/reset, vector control, PG feedback control, MODBUS
communication, abnormal reset, abnormal re-start, fan control, distance control
mode 1&2, multi-step control mode 1&2&3, demo mode, door width auto-tuning
Protection Functions
Over voltage, over current, under voltage, under current, external fault, overload,
ground fault, overheating, electronic thermal, PG feedback error, limit signal
error, open/close door time-out, re-open/re-close
Display Keypads
6-key, 4-digit, 7-segment LED, 4 status LEDs, master frequency, output
frequency, output current, custom units, parameter values for setup, review and
faults, RUN, STOP, RESET, FWD/REV
Enclosure Rating IP20
Pollution Degree 2
Installation Location Altitude 1,000 m or lower, keep from corrosive gasses, liquid and dust
Ambient Temperature -10
o
C to 40
o
C Non-Condensing and not frozen
Storage/ Transportation
Temperature
-20
o
C to 60
o
C
Ambient Humidity Below 90% RH (non-condensing)
Enviromental Conditions
Vibration 9.80665m/s2 (1G) less than 20Hz, 5.88m/s2 (0.6G) at 20 to 50Hz
Approvals
