Delta VFD-M-D series User Manual

Appendix B Accessories|VFD-M-D Series
Revision Jan. 2007, MDE2, SW V1.05 B-11
B.5 Non-fuse Circuit Breaker Chart
Per UL 508C, paragraph 45.8.4, part a:
For 1-phase drives, the current rating of the breaker shall be 4 times maximum input current rating.
(Refer to Appendix A for rated input/output current)
1-phase
Model Recommended non-fuse breaker (A)
VFD004M21B-D 6.3
B.6 Fuse Specification Chart
Smaller fuses than those shown in the table are permitted.
Line Fuse
Model
I (A)
Input
I (A)
Output
I (A) Bussmann P/N
VFD004M21B-D 6.3 2.5 15 JJN-15
