Page #36 background image
Chapter 5 Parameters|VFD-M-D Series
Revision Jan. 2007, MDE2, SW V1.05 5-3
Parameter Explanation Settings
Factory
Setting
Customer
0-10
PWM Carrier
Frequency
Selections
01~15 kHz 12
00: AVR function enable
01: AVR function disable
0-11 AVR Function
02: AVR function disable for decel.
00
00: Digital keypad
01: External terminals. Keypad STOP enabled.
02: External terminals. Keypad STOP disabled.
03: RS-485 serial communication (RJ-11).
Keypad STOP enabled.
0-12
Source of
Operation
Command
04: RS-485 serial communication (RJ-11).
Keypad STOP disabled.
00
00: Ramp to stop; E.F.: coast to stop
01: Coast to stop; E.F.: coast to stop
02: Ramp to stop; E.F.: ramp to stop
0-13 Stop Method
03: Coast to stop; E.F.: ramp to stop
00
00: Enable door open/close operation
01: Disable door open operation
0-14 Door Open/Close
Control
02: Disable door close operation
00
00: No limit signal
01: Door open limit signal only
02: Door close limit signal only
03: Door open and close limit signal
0-15 Position Mode
04: Detect by PG number and also accept
external door open/close limit signal
00
00: Always fan on
01: Drive stops 1 minute later, fan stop running
02: Run and fan on, stop and fan off
0-16 Fan Control
03: Preliminary temperature attained, fan start
to run (when temperature is equal or higher
than 60
o
C, it runs. When it is less than 40
o
C, it stops.
03
0-17
Stall Current Level
of Position Mode
0.0~200.0% 30.0
00: V/F control
0-18 Control Methods
01: Vector Control
00
Group 1 Basic Parameters
Parameter Explanation Settings
Factory
Setting
Customer
1-00
Maximum Output
Frequency (Fmax)
50.00 to 400.0 Hz 60.00
1-01
Maximum Voltage
Frequency (Fbase)
0.10 to 400.0 Hz 60.00
1-02
Maximum Output
Voltage (Vmax)
230V series: 0.1V to 255.0V 220.0
1-03
Mid-Point Frequency
(Fmid)
0.10 to 400.0 Hz 0.50
