Delta VFD-M-D series User Manual

Chapter 5 Parameters|VFD-M-D Series
Revision Jan. 2007, MDE2, SW V1.05 5-5
Parameter Explanation Settings
Factory
Setting
Custome
r
2-10
Compensation
Coefficient for Motor
Instability
00 to 16 07
2-11 PG Pulse Range 00 to 4000 600
00: Disable
01: Forward / Counterclockwise rotation
2-12 PG Input
02: Reverse / Clockwise rotation
00
2-13 Electrical Gear A 01 to 5000 100
2-14 Electrical Gear B 01 to 5000 100
2-15
ASR (Auto Speed
Regulation for door
open) control (with
PG only) (P)
0.0 to 10.0 0.5
2-16
ASR (Auto Speed
Regulation for door
open) control (with
PG only) (I)
0.00 to 100.00 (0.00 disable) 1.00
2-17
PG Slip
Compensation Limit
0.00 to 10.00 Hz 10.00
2-18
Deviation Range of
PG Feedback Signal
Error
0.01 to 100 Hz 3.00
2-19
PG Feedback Signal
Detection Time
0.0 to 100.0 sec 2.0
00: Warn and keep operation
01: Fault and RAMP to stop
2-20
Treatment of the
Erroneous PG
Feedback Signals
02: Warn and low speed operation
02
2-21
Sample time for
refreshing the
content of 210DH
and 210EH
0.01 to 1.00 sec 0.10
2-22
Door Width Auto-
tuning Frequency
0.10 to 1.00 sec 0.10
00: disable
2-23
Door Width Auto-
tuning Function
01: enable
00
2-24
Door Width Pulses
(Unit: 1)
01 to 9999 7500
2-25
Door Width Pulses
(Unit: 10000)
00 to 99 00
2-26 Reserved
2-27 Reserved
2-28
ASR (Auto Speed
Regulation for door
close) control (with
PG only) (P)
0.0 to 10.0 0.5
