7.7 Connection on a master controller via the Fieldbus (optional)
7.7.1 Profibus DP / Profinet
The device files for Profibus and Profinet may be downloaded via the web interface of the
AST11 (see 8.3.4.17 Tools  Fieldbus).
7.7.1.1 General Information
All the program modules necessary for Profibus or Profinet connection to a Siemens S7 -
controller are available in the DEPRAG_AST11PNDP.zip software package.
IMPORTANT
The modules must be used only for S7 - controllers with integrated Profibus
master or Profinet interface.
7.7.1.2 Hardware configuration
7.7.1.2.1 Profibus DP
Figure 9: Hardware configuration of Profibus DP
