73
9.3.1.4.2 Time Frame
The time frame for the screw-joint may be changed.
To change the value, proceed as follows:
• Use the left function key „Modify?“
• input the value for the minimum cycle time and confirm the input with the ENTER-key
• then input the value for the maximal cycle time and confirm your input with the Enter-
key
Use the right function-key „Set?“ to activate your setting.
9.3.2 Diagnostic Functions
The diagnostic functions allow the operator to analyze each screw-joint and to automati-
cally establish values for the time-frame. These values are only estimates and have to be
fine adjusted, if needed.
The analysis acquires values from 5 screw-joints.
Proceed as follows:
• First, input the program number, which is used for the analysis.
• Thereafter, process the first screw-joint; the actual screwdriving time is displayed.
• Now, process the next screw-joint, and so on.
After the fifth screw-joint, the minimum and maximum screwing time is displayed, with an
added upper and lower 20% offset. Use the left function key to activate this setting.
Error screw-joints will be ignored!
You may leave the diagnostic function at any time by pressing the ESC-key, without sav-
ing any of the adjustments.´
IMPORTANT
If a feeder is attached to the screwdriver, the screw has to be manually
reloaded, so that this diagnostic analysis can be made.
9.4 Interfaces
A detailed description of the ports can be found in the section 6.2.5 I/O Interface.
