12 Documentation
The sequence controller AST11 provides a wide variety of documentation possibilities.
12.1 Final values
If the command 'save value' is used on the screwing program, then the screwing results
are stored in a CSV data and can be loaded by the sequence controller via the web inter-
face (see also 8.3.4.7 Process Data Final ValuesProcess Data ). The command
"save values" can be used as often as you like within the screwing process, however, only
the three last values are saved. In case of a fault these values are always saved.
IMPORTANT
The data is only available if the screwing program has received the com-
mand "save final values" or if a faulty screwing application is present.
One CSV data per day is saved. The last data of the last seven days is always available.
The final values of the screwing application that are older than seven days are overwritten
by new final values.
The final value data of the last screwing application are also saved in the file "actual.csv".
The files are subject to the same limitations as described in chapter 12.2 Curve Represen-
tation for the curve data.
The CSV file is structured as follows:
• First line: Title bar with caption of the values
• Following line: results of a screwing application per line
Value Description
Date Date of screwing application
Time Time of screwing application
Program number Program used
Status Status, also see 14.2 Error in the screwing sequence
Total duration Total duration of the program
Step1 Step number of the first saved step
Moment1 Torque of the first saved step
Angle1 Angle of tilt of the step of the first saved step
Step2 Step number of the second saved step
Moment2 Torque of the second saved step
Angle2 Angle of tilt of the second saved step
Step3 Step number of the third saved step
Moment3 Torque of the step of the third saved step
Angle3 Angle of tilt of the step of the third saved step
Step not OK Step number of the faulty step
MomentNotOK Torque of the faulty step
AngleNotOK Angle of tilt of the faulty step
FC Status Not available for AST11
FC counter Not available for AST11
Torque unit Unit torque
Angle unit Angle of rotation unit
Table 25: Structure of the data set
