58
The following data are recorded:
• speed
• torque
• angle
• program step
• current
• screwdriver temperature
8.3.4.7 Process Data Final Values
This page offers the possibility to save the final values of all assemblies of the last seven
days as csv-values (refer to 12.1 Final values).
Figure 23: Screwdriver results
The files have the same limits for CSV-data as described in 12.2 Curve Representation.
The final values, which are older than seven days, will be replaced by new final values.
Additionally the final data of the last screwdriving are saved into a file called “actual.csv”.
This file can also be downloaded from this page.
IMPORTANT
This data are only available, if the screwdriving program contains the
command „Save Values“ or if a sequence error has occurred.
