7.7.1.3.4 Description – Error Codes
Error Description
FF00
Error in the input address range
Cause:
The interface parameter I_AddrX (X=1-4) does not have a value or has one that is
<= 0.
FF01
Error while reading the input module 1 (I_Addr1)
Possible causes:
- An incorrect input module has been entered in the hardware configuration. In-
put module 1 must be configured with "64 bytes in".
Incorrect start address of the input module 1 at the interface parameter I_Addr1
FF02
Error while reading the input module 2 (I_Addr2)
Possible causes:
- An incorrect input module has been entered in the hardware configuration. In-
put module 2 must be configured with "64 bytes in".
Incorrect start address of the input module 2 at the interface parameter I_Addr2
FF03
Error while reading the input module 3 (I_Addr3)
Possible causes:
- An incorrect input module has been entered in the hardware configuration. In-
put module 3 must be configured with "64 bytes in".
Incorrect start address of the input module 3 at the interface parameter I_Addr3
FF04
Error while reading the input module 4 (I_Addr4)
Possible causes:
- An incorrect input module has been entered in the hardware configuration. In-
put module 4 must be configured with "32 bytes in".
Incorrect start address of the input module 4 at the interface parameter I_Addr4
FF10
Error in the output address range
Cause:
The interface parameter O_AddrX (X=1-4) does not have a value or has one that is
<= 0.
FF11
Error while writing to the output module 1 (O_Addr1)
Possible causes:
- An incorrect output module has been entered in the hardware configuration.
Output module 1 must be configured with "64 bytes out".
Incorrect start address of the output module 1 at the interface parameter O_Addr1
FF12
Error while writing to the output module 2 (O_Addr2)
Possible causes:
- An incorrect output module has been entered in the hardware configuration.
Output module 2 must be configured with "64 bytes out".
Incorrect start address of the output module 2 at the interface parameter O_Addr2
FF13
Error while writing to the output module 3 (O_Addr3)
Possible causes:
- An incorrect output module has been entered in the hardware configuration.
Output module 3 must be configured with "64 bytes out".
Incorrect start address of the output module 3 at the interface parameter O_Addr3
FF14
Error while writing to the output module 4 (O_Addr4)
Possible causes:
- An incorrect output module has been entered in the hardware configuration.
Output module 4 must be configured with "32 bytes out".
Incorrect start address of the output module 4 at the interface parameter O_Addr4
F100
Timeout error in the fieldbus communication
Table 12: Description – Error Codes
