76
active Indicates whether F-control is active.
Reset by Button If there is an error in screw assembly the reset button
can be pressed.
Release by Button Once screw assembly on a part is finished this button
releases the part.
Number of Cycles Number of screw assemblies per component
Minimum Time Minimum screw assembly time
F-Control
Maximum Time Maximum screw assembly time
Table 17: Adjustable parameters
10.1.2 Special parameters for fieldbus systems (optional)
10.1.2.1 Profibus
Parameter Description
Profibus address Address under which the AST11 is accessible in the
Profibus.
Table 18: Configurable Profibus parameters
10.1.2.2 Profinet
Parameter Description
IP address The IP address via which the AST11 is accessible in
the network via Profinet.
Net mask It designates the network segment in which the
AST11 sequence controller lies.
Gateway The IP address of the gateway for the network seg-
ment in which the AST11 sequence controller lies.
Station name Station name of the AST11 in the Profinet.
Table 19: Configurable Profinet parameters
10.1.2.3 Ethernet IP
Parameter Description
IP address The IP address via which the AST11 is accessible in
the network via Ethernet IP.
Net mask It designates the network segment in which the
AST11 sequence controller lies.
Gateway The IP address of the gateway for the network seg-
ment in which the AST11 sequence controller lies.
DHCP If DHCP is active, the network addresses set / dis-
played are not valid. They are assigned via a DHCP
server.
BOOTP If BOOTP is active, the network addresses set / dis-
played are not valid. They are assigned via BOOTP.
Table 20: Configurable Ethernet IP parameters
10.1.2.4 Ethercat
No settings are necessary.
