66
Select an available program step by clicking this step. Subsequently click the strategy or
the command that you like to insert. If you click "insert before", the strategy or command
should be inserted in front of the currently selected program step or click "insert after", if
the strategy or the command should be inserted behind the currently selected program
step.
IMPORTANT
If the screwing program is still empty, then the strategy or command is
always inserted as first parameter step.
Figure 38: Screwdriving sequence
View/process a program step:
Select an available program step by clicking this step. The parameters of this step are dis-
played. A new value can be directly entered in the input field next to the parameter.
Save program:
Click the "Submit" button, which can be found below the last program step in order to save
the program step and the parameters.
Copy program:
If you want to save an available program under another program number, select the new
program number from the list field next to the "submit as" button. The "submit as" button
can be found below the last program step. Subsequently click on "submit as" in order to
save the program under a new number.
Printing a program:
If you would like to print out a program, click on the "Print Preview" button. To return to the
normal view, press the "Normal View" button.
Deleting a program step or a program:
If you would like to delete individual program steps, click on the "Remove" button of the
step that needs to be deleted. If you would like to delete the entire screwdriver program,
click on the "Remove" button on the right next to the title of the screwdriver program. If you
would like to delete all screwdriver programs, first click on the 'General' tab and then on
the "Delete all programs" button.
