8 Instructions for the Sequence Controller
8.1 General
The sequence controller can be programmed by using the WEB-Interface or by the inte-
grated numeric keypad, whereby the programming choices on the keypad are more lim-
ited.
The sequence controller can be operated as a stand-alone unit or it can be operated by a
PLC.
8.2 Operating Elements
Figure 11: Operating Elements
8.2.1 Functional Display (LEDs)
The LED’s located below the display notify the user about the operating status of the se-
quence controller:
Color Description Meaning
yellow Power all voltage are O.K.
blue ready the sequence controller is ready
green Status  last screw assembly was O.K.
red Status  last screw assembly was not O.K.
Table 14: LEDs
function keys
functional display
menu- and cursor keys
numerical keys
