Det-Tronics Eagle Quantum Premier - Eq21 Xxps Power Supplies; HART Interface Module

6-8
95-8533
18.2
Note: Refer to Appendix C for ATEX and IECEx
approval details and Special Conditions for
Safe Use.
Refer to Appendix D for USCG Approval details.
HART INTERFACE MODULE
(HIM)
INPUT VOLTAGE—
24 vdc nominal, 18 to 30 Vdc. 10% overvoltage
will not cause damage to the equipment.
INPUT POWER—
1.0 watt maximum.
INPUT/OUTPUT CURRENT—
Operating: 4 -20 mA.
Maximum: 0-30 mA.
TEMPERATURE RANGE—
Operating: –40°F to +185°F (–40°C to +85°C).
Storage: –-67°F to +185°F (–55°C to +85°C).
HUMIDITY RANGE—
5 to 95% RH, non-condensing.
DIMENSIONS—
See Figure 6-2.
SHIPPING WEIGHT—
0.5 pounds (0.2 kilograms)
CERTIFICATION—
FM / CSA: Class I, Div. 2, Groups A, B, C, D (T4).
Class I, Zone 2, Group IIC (T4 ).
CE: ATEX/EMC Directive Compliant.
ATEX
FM
APPROVED
®
II 3 G.
Ex nA IIC T4 Gc.
DEMKO 04 ATEX 136507X.
T
amb
= –40°C to +85°C.
IECEx: IECEx ULD 10.0004X.
Ex nA IIC T4 Gc.
T
amb
= –40°C to +85°C.
Note: Refer to Appendix C for ATEX and IECEx
approval details and Special Conditions for
Safe Use.
EQ21XXPS POWER
SUPPLIES
INPUT VOLTAGE—
Selectable for 120, 208 or 240 vac input power,
±10%.
INPUT CURRENT—
60 Hz Models:
EQ2110PS: 4 amps at 120 VAC
EQ2130PS: 11 / 6 / 6 amps at 120 / 208 /
240 VAC
EQ2175PS: 24 / 15 / 12 amps at 120 / 208 /
240 VAC.
50 Hz Models:
EQ2111PS: 4 amps at 120 VAC
EQ2131PS: 6 amps at 240 VAC
EQ2176PS: 12 amps at 240 VAC
OUTPUT CURRENT—
EQ2110PS / EQ2111PS: 10 amperes at
24 Vdc
EQ2130PS / EQ2131PS: 30 amperes at
24 Vdc
EQ2175PS / EQ2176PS: 75 amperes at
24 Vdc
POWER CONSUMPTION—
EQ2110PS / EQ2111PS: 46 Watts
EQ2130PS / EQ2131PS: 140 Watts
EQ2175PS / EQ2176PS: 349 Watts
TEMPERATURE RANGE—
Operating: +32°F to +122°F (0°C to +50°C)
Storage: -40°F to +185°F (-40°C to +85°C)
HUMIDITY RANGE—
5 to 95% RH, non-condensing.
DIMENSIONS—
in Inches (Centimeters)
Width Height Depth
EQ211xPS: 19 (48.3) 7 (17.8) 15 (38.1)
EQ213xPS: 19 (48.3) 14 (35.6) 15 (38.1)
EQ217xPS: 19 (48.3) 14 (35.6) 15 (38.1)
NOTE
Power supplies are designed for
mounting in a standard 19 inch rack.
Optional mounting hardware is available
for oor or wall mount applications.
CERTIFICATION—
FM / CSA: Ordinary locations.
FM
APPROVED
®
FM
APPROVED
®
