Determining Power Requirements
Tables 3-1 and 3-2 are provided for calculating
the total current requirements for those parts of
the system requiring battery backup.
Table 3–1—Standby Current Requirements at 24 Vdc
Notes: Standby current is the average current draw for the device in normal mode.
This table is for battery calculations only.
For OPECL standby current requirements, reference versions 16.1 and earlier of this manual.
Device Type
Number of
Devices
Standby
Current
Total Current for Device Type
EQP Controller X 0.360 =
EQ3LTM Module X 0.001 =
EDIO Module X 0.075 =
DCIO Module X 0.075 =
Power Supply. Monitor X 0.060 =
IDC/IDCGF/IDCSC X 0.055 =
X3301/X3301A - without heater
X 0.160 =
X3301/X3301A - with heater X 0.565 =
X3302 - without heater X 0.160 =
X3302 - with heater X 0.565 =
X2200 X 0.135 =
X9800 - without heater X 0.085 =
X9800 - with heater X 0.420 =
X5200 - without heater X 0.155 =
X5200 - with heater X 0.490 =
Relay Module X 0.120 =
Analog Input Module X 0.160 =
EQ2220GFM X 0.018 =
PIRECL X 0.270 =
LS2000 Transmitter without heater
X 0.149 =
LS2000 Transmitter with heater
X 0.336 =
LS2000 Receiver without heater
X 0.116 =
LS2000 Receiver with heater X 0.258 =
Network Extender X 0.090 =
ASM/ASH Module X 0.560 =
EQ21xxPS Power Supply X 0.350 =
UD10DCU - with heater off X 0.054 =
UD10DCU - with heater on X 0.167 =
UD10DCU CGS - w/ heater off X 0.221 =
UD10DCU CGS - w/ heater on X 0.333 =
Other X =
Total Standby Current for System (in amperes) =
