Table 3-2—Alarm Current Requirements at 24 Vdc
Device Type
Number of
Devices
Alarm Current Total Current for Device Type
EQP Controller X 0.430 =
EQ3LTM Module X 0.001 =
EDIO 8 Inputs X 0.130 =
EDIO 8 Outputs X 0.075 =
DCIO 8 Inputs X 0.130 =
DCIO 8 Outputs X 0.075 =
Relay Module X 0.120 =
Power Supply Monitor X 0.060 =
IDC/IDCGF/IDCSC X 0.090 =
X3301/X3301A - w/o heater X 0.160 =
X3301/X3301A - with heater X 0.565 =
X3302 - without heater X 0.160 =
X3302 - with heater X 0.565 =
X2200 X 0.135 =
X9800 - without heater X 0.085 =
X9800 - with heater X 0.420 =
X5200 - without heater X 0.155 =
X5200 - with heater X 0.490 =
Analog Input Module X 0.300 =
EQ2220GFM X 0.018 =
PIRECL X 0.275 =
LS2000 Transmitter without heater X 0.149 =
LS2000 Transmitter with heater X 0.336 =
LS2000 Receiver without heater X 0.182 =
LS2000 Receiver with heater X 0.326 =
Network Extender X 0.090 =
EQ3760ASM Module X 0.560 =
EQ21xxPS Power Supply X 0.350 =
UD10DCU - with heater off X 0.054 =
UD10DCU - with heater on X 0.167 =
UD10DCU CGS - with heater off X 0.221 =
UD10DCU CGS - with heater on X 0.333 =
Other X =
Total Solenoid Load +
Total Signaling Load +
Total Alarm Current for System (in amperes) =
Notes: This table is for battery calculations only.
For OPECL alarm current requirements, reference versions 16.1 and earlier of this manual.
