Det-Tronics Eagle Quantum Premier - EQ3710 AIM Analog Input Module; EQ3720 Relay Module

95-8533
6-7
18.2
EQ3720 RELAY MODULE
POWER REQUIREMENTS—
3 watts nominal, 4 watts maximum.
INPUT VOLTAGE—
24 Vdc nominal, 18 to 30 Vdc. 10% overvoltage
will not cause damage to the equipment.
RELAY CONTACTS—
30 Vdc, 1 amps resistive.
LON COMMUNICATION—
Digital communication, transformer isolated
(78.5 kbps).
TEMPERATURE RANGE—
Operating: –40°F to +185°F (–40°C to +85°C).
Storage: –67°F to +185°F (–55°C to +85°C).
HUMIDITY RANGE—
5 to 95% RH, non-condensing.
DIMENSIONS—
Refer to Figure 6-3.
SHIPPING WEIGHT—
1 pound (0.45 kilograms).
CERTIFICATION—
FM / CSA: Class I, Div. 2, Groups A, B, C, D (T3C).
Class I, Zone 2, Group IIC (T3).
Refer to Appendix A for FM Approval details.
Refer to Appendix B for CSA Approval details.
Refer to Appendix D for USCG Approval details.
CE: ATEX/EMC Directive Compliant.
ATEX:
FM
APPROVED
II 3 G.
Ex nA nC IIC T3 Gc.
DEMKO 03 ATEX 135246X.
Tamb = –40°C to +75°C.
IECEx: IECEx ULD 10.0004X.
Ex nA nC IIC T3 Gc.
Tamb = –40°C to +75°C.
Note: Refer to Appendix C for ATEX and IECEx
approval details and Special Conditions for
Safe Use.
RESPONSE TIME—
Actuates in <0.15 second after acknowledging
an alarm command message.
EQ3710AIM ANALOG
INPUT MODULE
POWER REQUIREMENTS—
Module power consumption: 6 watts.
When supplying power to three-wire
transmitters:
Maximum current at power input: 7.4 amperes.
Output current: 900 mA per channel maximum.
INPUT/OUTPUT VOLTAGE—
24 Vdc nominal, 18 to 30 Vdc. 10% overvoltage
will not cause damage to the equipment.
TEMPERATURE RANGE—
Operating: –40°F to +185°F (–40°C to +85°C).
Storage: –67°F to +185°F (–55°C to +85°C).
HUMIDITY RANGE—
0 to 95% RH, non-condensing.
CHANNEL ACCURACY—
Zero: ±0.3% full scale from –40°C to +85°C.
Span: ±0.5% full scale from –40°C to +85°C.
RESPONSE TIME—
1 to 100 LON devices: < 2 seconds
101 to 200 LON devices: < 3 seconds
201 to 246 LON devices: < 4 seconds
LON COMMUNICATION—
Digital communication, transformer isolated
(78.5 kbps).
DIMENSIONS—
Refer to Figure 6-3.
SHIPPING WEIGHT—
1 pound (0.45 kilograms).
CERTIFICATION—
FM / CSA: Class I, Div. 2, Groups A, B, C, D (T4).
Class I, Zone 2, Group IIC (T4).
Refer to Appendix A for FM Approval details.
Refer to Appendix B for CSA Approval details.
CE: ATEX/EMC Directive Compliant.
ATEX:
FM
APPROVED
II 3 G.
Ex nA nC IIC T4 Gc EN60079-29-1.
DEMKO 03 ATEX 136207X.
T
amb
= –40°C to +85°C.
IECEx: IECEx ULD 10.0004X.
Ex nA nC IIC T4 Gc.
T
amb
= –40°C to +85°C.
