6-6
95-8533
18.2
CE: ATEX/EMC Directive Compliant.
ATEX:
II 3 G.
Ex nA nC IIC T4 Gc.
DEMKO 02 ATEX 133864X.
Tamb = –40°C to +85°C.
IECEx: IECEx ULD 10.0004X.
Ex nA nC IIC T4 Gc.
Tamb = –40°C to +85°C.
Note: Refer to Appendix C for ATEX and IECEx
approval details and Special Conditions for
Safe Use.
INPUT / INITIATING DEVICE CIRCUITS
UNSUPERVISED INPUT—
Two state input (on/off).
Normally open contact.
SUPERVISED INPUT, CLASS B—
Two state input (active/trouble):
– End of Line Resistor 10 K ohms nominal
– Open Circuit > 45 K ohms
– Active Circuit < 5 K ohms.
SUPERVISED INPUT, CLASS B—
Three State input (active/short/open):
– End of Line Resistor 10 K ohms nominal
– In Line Resistor 3.3 K ohms nominal
– Open Circuit > 45 K ohms
– Short Circuit < 1.4 K ohms
– Active Circuit 2.5 K ohms to 5 K ohms.
INPUT, TYPES—
Configurable for fixed logic applications:
– Fire Alarm
– Supervisory
– Trouble
– High Gas Alarm
– Low Gas Alarm
– Other.
OUTPUT / NOTIFICATION / RELEASING
CIRCUITS
UNSUPERVISED OUTPUT RATING—
Short circuit protected: 2 amperes at 30 Vdc
maximum.
SUPERVISED OUTPUT RATING—
SIGNALING CIRCUIT
MAXIMUM OUTPUT CURRENT—
2 amperes maximum, 15 Amp inrush.
Automatic short circuit protection provided.
SUPERVISORY CURRENT—
Reverse current monitored at 3.0 mA, ± 2.0
mA.
RESPONSE TIME—
Output actuates in <0.15 second after
acknowledging an alarm command message.
EOL RESISTORS—
10 K ohms ±2 K ohms.
SIGNALING OUTPUT, TYPES—
Configurable for device applications:
– Continuous
– 60 beats per second
– 120 beats per second
– Temporal Pattern.
NOTE
All eight channels are synchronized
when programmed as a signaling output.
SUPERVISED OUTPUT RATING—
RELEASING CIRCUIT
MAXIMUM OUTPUT CURRENT
(Per Channel)—
2 amperes maximum, 15 Amp inrush.
Automatic short circuit protection provided.
SUPERVISORY CURRENT—
Monitored at 3.0 mA ±2.0 mA.
RESPONSE TIME—
Output actuates in <0.15 second after
acknowledging an alarm command message.
RELEASING OUTPUT, TYPES—
Configurable for device applications:
– Continuous
– Timed.
