No. Part name Description
1 Copy output tray Collects copies and printouts fed out facing down.
2 Front door Opened when replacing the toner bottle. (See p. 8-4.)
3 1st paper drawer • Can be loaded with up to 250 sheets of paper
• The paper size can be adjusted freely.
• Special paper can be loaded. (See p. 7-23.)
4 Manual bypass tray • Used for manually feeding paper for making copies.
• Load only one sheet of paper at a time.
• Special paper can be loaded. (See p. 5-16.)
5 Right-side door re-
lease lever
Used to open/close the right-side door.
6 Right-side door Opened when clearing paper misfeeds.
7 Mechanical counter Indicates the total number of copy and printout s that were print-
ed.
8 RJ45 connector for
networking (optional)
Used for connecting the network cable when this machine is used
for network printing.
9 USB connector Used for connecting a USB cable from the computer.
10 Power switch Used to turn the machine on and off. (See p. 3-19.)
11 Control panel Used to start copying or sending or to specify various settings.
(See p. 3-13.)
