Precaution
3
ineo 163/213 3-9
Automatic document feeder/multi bypass tray (optional)
Automatic document feeder
Multi bypass tray
1
23
4
56
No. Part name Description
1 Adjustable docu-
ment guide
Adjust the guide to the width of the document (See p. 4-18.)
2 Misfeed-clearing
cover
Opened when clearing paper misfeeds. (See p. 8-19.)
3 Document feed tray Load the documents to be copied face up. (See p. 4-18.)
4 Document output
tray
Collects documents that have been scanned.
No. Part name Description
5 Tray extension Pulled out when large-sized paper is loaded.
6 Bypass tray Can be loaded with up to 100 sheets of plain paper, 20 sheets of
special paper, or 10 envelopes. (See p. 5-16.)
