Digi SM-720 - Battery Location on Mainboard

158 pages

To Next Page

To Previous Page

SM-500V2 Service Manual Edition 5

108

Items Y N Identification Removal

procedure

Comments

Rear Display Assembly

12.2 Location of Battery in Main-board

MAIN BD BLK AG (SM-720)

44011690100700

Lithium Battery

(BT1)

Main Page

Table of Contents2
