22. Tighten the screw. 23. Pull out the pin lock then assy
side cover from front direction.
24. Assemble printer cover.
25. Rotate clock-wise locking
bracket 90 degrees as shown.
26. Assy bracket BN (triangle) by
tightens screw.
27. Assemble back dome cover.
10.3.2 Hanging Scale WLAN Bridge Configuration
Please refer to
10.1.3 WLAN Bridge Configuration Setup.
