Digi SM-720 - RS232 C and RS485 Wiring

SM-500V2 Service Manual Edition 5
99
11.5.4 RS232C and Multi-Drop (4 Line, RS485) Wire
Connector Type
9 Pin D-Sub Connector
Female (Back View)
25 Pin D-Sub Connector
Female (Back View)
9 Pin D-Sub Connector
Male (Back View)
25 Pin D-Sub Connector
Male (Back View)
8 Pin DIN Plug
Male (Front View)
PC (9 PIN) TO LCU 401
(FOR PC to LCU 401 communication)
9 Pin D-Sub (Female) 25 Pin D-Sub (Male)
