Digi SM-720 Service Manual

SM720 Service Manual Edition 5
63
8.4 Pole Display Disassembly
8.5 Bench Display Disassembly
Screw Type:
101 – Truss Head M4x10
102 – Flat Head M3x10
103 – Washer (A)-4
104 – Binding Head M3x6
105 – SEMS B M4x16
102
102
102
102
103
103
103
103
101
101
104
104
104
104
105
Case BH (800LCD, Y033)
44011602303400
LCD W/CCFL 5399FB
12AXLCD05399FB
Cover BP
(Pole Bottom)
Front Display
Rear Display
Screw Type:
101 – SEMS B M3x8
102 – SEMS B M3x10
103 – Binding Head M3x6
104 – SEMS B M3x6
101
101
101
102
103
103
103
103
103
104
104
104
104
104
104
104
104
104
104
103
103
103
103
Insulator AB (800LCD)
44011104800200
LCD W/CCFL 5399FB
12AXLCD05399FB
Cover AL (32 Keys)
44011602801202
ELEC ASSY AJ (K/B, 32)
44011690901000
ELEC ASSY BI
(DISP BD, B Front)
44011690903500
Case AB
(Common Bottom)
Cover AT (Front 50)
