SM720 Service Manual Edition 5
71
8.8 Hanging Type Keyboard Disassembly
8.9 Hanging Type Front & Rear Display Disassembly
Screw Type:
101 – SEMS B M3x6
102 – PAKKIN (A)-1
101
101
101
101
101
101
101
101
101
101
Screw Type:
101 – SEMS B M3x6
102 – SEMS B M3X8
101
102
102
102
102
101
101
101
WELASSY AF (FRONT)
44013550200601
INSULATOR AJ (L-LCD)
44013550200601
LCD 5375 FNPWTNH
12AWCD05375FKP
BKT AD (SM500H REAR)
44013501800404
LCD5375 FNPWTNH
12AWCD05375FNP
101
101
101
101
101
101
PCB TW1231-0
(56 Preset Key)
22TWB000012310
102
102
101
101
