SM720 Service Manual Edition 5
19
4. INITIAL SETUP
4.1 Pole, Bench and Elevated Type
4.1.1 Scale Assembly
4.1.1.1 Display Pole Kit Mounting
4.1.1.2 Level Adjustment
4.1.2 Default Country Spec Setting
There are two methods for default country spec setting.
Default Country Specification Method 1:
Default Customer Specification and Weight & Measure Specification setting of individual country.
(Please turn on the span switch before proceed this process.)
Key to press Operation
+ Switch On the Power.
-- Show current country SPEC then default
Customer Specification setting.
-- Follow the instruction:
a) Press the [Clear] then
b) Press the [Print] process to next step
CURRENT COUNTRY SPECIFICATION
PRESS ‘CLEAR’ KEY, THEN PRESS ‘PRINT’ KEY
1. Place the display Pole inside the pole bottom
(base AB)
2. Align the four holes of the display pole and
tighten screw Flat Head M4x16 (4pcs).
Place the scale on the flat surface and adjust the
four legs until the bubble on the level is in the
center as shown above.
54-WG
To Next Page
